EMER/LED Emergency Light

Features

  • Available on QuickShip
  • Ultra-bright, energy-efficient, long-life LEDs
  • High-performance reflector and plastic lens provide optimal light distribution
  • Optional high lumen lamp heads
  • Provides 90 minutes of emergency operation
  • Adjustable heads provide optimal center-to-center spacing
  • Fully automatic solid-state two-rate charger recharges battery in 24 hours
  • Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing
  • Self-diagnostic option performs monthly, biannual, and annual tests to ensure reliable operation and meets electrical and life safety codes
  • Optional polycarbonate shield and wireguard provide added protection
  • Remote capable available

Tools

Product Builder

Configure fixtures and streamline the ordering process.

Use your zip code to find your local agent.

Specifications

Housing

Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.

Lamp Heads

Chrome-plated metallized reflector and plastic lens.

Electrical

Dual 120/277 voltage standard. 1.0 watt (8 LEDs x 0.125W) per head. 3.6V long life, maintenance-free, rechargeable NiCd battery. 3W remote capacity when specified with RC option.

Mounting

Wall or ceiling mount. Knockout for conduit applications. Universal knockout pattern on back plate for surface mount.

Listings

• UL 924 standard as an emergency light suitable for dry or damp locations (0°C - +50°C).
• Meets NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.

Warranty

5-year limited warranty.

Accessories

Polycarbonate Shield

Wireguard

Housing Colors

Industry-Standard White

Black
