H.E. Williams, Inc. Quickship Lighting Products

QuickShip

Shipping in 48 Hours

The Williams QuickShip program offers a competitive suite of top-selling products to support immediate lighting requirements on any job. Shipping within 48 hours, our centrally located manufacturing facility ensures quick delivery.

Quickship Requirements

  • Orders must consist of QuickShip items ONLY.
  • "QuickShip" MUST be referenced in the subject line on all requests.
  • Standard freight terms apply.

Filter Products

Section
Clear Filters

17 | Narrow Low-Profile Wrap

  • Low-profile wrap-around provides uniform downward light distribution and subtle side illumination.
  • Shallow depth provides sleek, low-profile appearance.
  • Mounts easily as a single fixture or in continuous row installations.

LED
Fixture Standards: 4' • Frosted prismatic acrylic diffuser • 10% dimming for 0-10V applications • Universal voltage

Series Description
17-4-L55/835-AF-QS-DIM-UNV 5,500 lumens • 3500K

Fluorescent
Fixture Standards: 4' • Clear prismatic acrylic diffuser • 32-watt T8 • Electronic ballast • Universal voltage

Series Description
17-4-232-A-QS-EB2*AD-UNV 2-Lamp

18 | Low-Profile Wrap

  • Low-profile wrap-around provides uniform downward light distribution and subtle side illumination.
  • Shallow depth provides sleek, low-profile appearance.
  • Mounts easily as a single fixture or in continuous row installations.

Fixture Standards: 4' • Clear prismatic acrylic diffuser • 32-watt T8 • Electronic ballast • Universal voltage

Series Description
18-4-432-A-QS-EB4*AD-UNV 4-Lamp

75S | Square Lens LED Strip

  • Available with fieldseleCCT – the simplest way to personalize lighting.
  • Diffuse acrylic lens enhances uniformity and minimizes glare
  • Square lens provide a clean look for architectural environments
  • Variety of surface and suspended mounting accessories

Fixture Standards: 10% dimming for 0-10V applications • Universal voltage

Description
75S-4-L45/8FS-QS-DIM-UNV 4' • 4,500 lumens • fieldseleCCT
75S-4-L60/8FS-QS-DIM-UNV 4' • 6,000 lumens • fieldseleCCT
75S-8-L120/8FS-QS-DIM-UNV 8' • 12,000 lumens • fieldseleCCT
75S-8-L90/8FS-QS-DIM-UNV 8' • 9,000 lumens • fieldseleCCT

76 | Standard Strip

  • Available in 4' and 8' lengths.
  • Channel connector furnished for continuous row applications (included with 8' units only).
  • Special reflectors are available for glare control and cutoff. LED technology provides high efficacy and energy efficiency.

LED
Fixture Standards: 10% dimming for 0-10V applications • Universal voltage

Series Description
76-4-L53/835-QS-DIM-UNV 4' • 5,300 lumens • 3500K
76-4-L53/840-QS-DIM-UNV 4' • 5,300 lumens • 4000K
76-8-L106/835-QS-DIM-UNV 8' • 10,600 lumens • 3500K
76-8-L106/840-QS-DIM-UNV 8' • 10,600 lumens • 4000K

Fluorescent
Fixture Standards: 32-watt T8 • Electronic ballast • Universal voltage

Series Description
76-4-232-QS-EB2*AD-UNV 4' • 2-Lamp
76-8-432-QS-EB4*AD-UNV 8' • 4-Lamp
R1240-4 REFLECTOR 4' Reflector

EXIT | Exit Sign

  • Compact, low-profile design.
  • Universal single/double face.
  • Removable directional indicators.

Fixture Standards: AC operation with emergency battery backup • Industry standard white housing • 120 & 277 dual voltage

Series Description
EXIT-R-EM-WHT-QS-D Red Letters

GL | Low-profile Industrial

  • Shallow fixture depth of less than 4"
  • Narrow distribution and uplight options provide tailored performance
  • Quick-wire access plate for easy installation

LED
Fixture Standards: 4' • VBY hangers • 10% dimming for 0-10V applications • Universal voltage

Series Description
GL-4-L300/840-(2)VBY/PWU-QS-DIM-UNV 30,000 lumens • 4000K
GL-4-L300/850-(2)VBY/PWU-QS-DIM-UNV 30,000 lumens • 5000K

Fluorescent
Fixture Standards: 4' • 54-watt T5HO • VBY hangers • Electronic ballast • Universal voltage

Series Description
GL-4-454T5H-(2)VBY/PWU-QS-EB4-UNV 4-Lamp
GL-4-454T5H-(4)F54/41 F&I-(2)VBY/PWU-QS-EB4*AD-UNV 4-Lamp Installed
GL-4-654T5H-(2)VBY/PWU-QS-EB4/2-UNV 6-Lamp
GL-4-654T5H-(6)F54/41 F&I-(2)VBY/PWU-QS-EB4/2*AD-UNV 6-Lamps Installed

HL | High Bay Industrial

  • Consumes less energy than metal halide or HPS and delivers comparable light levels when replaced one-for-one.
  • Multiple distributions and uplight options available.
  • Quick-wire access plate in back of fixture housing for easy attachment of incoming power supply.

Fixture Standards: 4' • 54-watt T5HO • Medium Distribution • VBY hangers • Electronic ballast • Universal voltage

Series Description
HL-4-454T5H-MD-(2)VBY/PWU-QS-EB4*AD-UNV 4-Lamp
HL-4-654T5H-MD-(2)VBY/PWU-QS-EB4/2*AD-UNV 6-Lamp

L60 | 6" Round – LED

  • 6" aperture provides up to 9,000 lumens.
  • LED module and driver accessible from below ceiling plane for ease of maintenance.
  • Aluminum reflector offers maximum optical performance and provides crisp, clean installation.

Fixture Standards: 80 CRI • 3500K CCT • Clear semi-specular reflector • Wide distribution • 10% dimming for 0-10V applications

Series Description
L60-L11C/835-CS/W-QS-DIM-120 1,100 lumens • 120V
L60-L11C/835-CS/W-QS-DIM-277 1,100 lumens • 277V
L60-L20C/835-CS/W-QS-DIM-120 2,000 lumens • 120V
L60-L20C/835-CS/W-QS-DIM-277 2,000 lumens • 277V

LPT | Low-Profile Troffer

  • 3-7/16" deep housing installs easily within limited plenum space.
  • Gasketed door frame features offset mitered corners to eliminate light leaks.
  • Cam latches close securely and allow hassle-free maintenance.

Fixture Standards: #12 pattern acrylic lens, .100" thick • T8 electronic ballast • Universal voltage

Series Description
LPT-22-232U-SA12100-QS-EB2*AD-UNV 2' x 2' • 2 U-Lamps
LPT-24-332-SA12100-QS-EB3*AD-UNV 2' x 4' • 3-Lamp
LPT-24-432-SA12100-(4)FO32/841/ECO F&I-QS-EB4*AD-UNV 2' x 4' • 4-Lamps installed
LPT-24-432-SA12100-QS-EB4*AD-UNV 2' x 4' • 4-Lamp

LT | LED Troffer

  • Easily change the color temperature on-site with fieldseleCCT®.
  • High efficacy fixture delivers up to 140 lm/W.
  • DLC Premium qualified.

Fixture Standards: Frosted acrylic lens • 80 CRI • 10% dimming for 0-10V applications • Universal voltage

Description
LT-22-L37/8FS-AF-QS-DIM-UNV 2' x 2' • 3,700 lumens • fieldseleCCT
LT-24-L57/8FS-AF-QS-DIM-UNV 2' x 4' • 5,700 lumens • fieldseleCCT
Standard Series Description
LT-14-L47/835-AF-QS-DIM-UNV 1' x 4' • 4,700 lumens • 3500K
LT-14-L47/840-AF-QS-DIM-UNV 1' x 4' • 4,700 lumens • 4000K
LT-22-L39/835-AF-QS-DIM-UNV 2' x 2' • 3,900 lumens • 3500K
LT-22-L39/840-AF-QS-DIM-UNV 2' x 2' • 3,900 lumens • 4000K
LT-24-L40/835-AF-QS-DIM-UNV 2' x 4' • 4,000 lumens • 3500K
LT-24-L40/840-AF-QS-DIM-UNV 2' x 4' • 4,000 lumens • 4000K
LT-24-L64/835-AF-QS-DIM-UNV 2' x 4' • 6,400 lumens • 3500K
LT-24-L64/840-AF-QS-DIM-UNV 2' x 4' • 6,400 lumens • 4000K

PT | Shallow Plenum LED Troffer

  • Easily change the color temperature on-site with fieldseleCCT®.
  • Slim 2-3/8” for minimal plenum space.
  • Recessed, surface and retrofit kit preserve continuity.

Fixture Standards: Diffuse ribbed acrylic lens • 80 CRI • 10% dimming for 0-10V applications • Universal voltage

Description
PT-22-L36/8FS-RA-QS-DIM-UNV 2' x 2' • 3,600 lumens • fieldseleCCT
PT-24-L55/8FS-RA-QS-DIM-UNV 2' x 4' • 5,500 lumens • fieldseleCCT
Standard Series Description
PT-22-L43/835-RA-QS-DIM-UNV 2' x 2' • 4,300 lumens • 3500K
PT-22-L43/840-RA-QS-DIM-UNV 2' x 2' • 4,300 lumens • 4000K
PT-24-L61/835-RA-QS-DIM-UNV 2' x 4' • 6,100 lumens • 3500K
PT-24-L61/840-RA-QS-DIM-UNV 2' x 4' • 7,800 lumens • 4000K

VWMH | Voltaire Mini Architectural Wall Pack

  • Designed to illuminate sidewalks, entryways, perimeters or facades.
  • Intended for use in both uplight and downlight applications.
  • Savings of up to 80% energy compared to HID systems.
  • Blends seamlessly with a variety of architectural styles.

Fixture Standards: 80 CRI • 4000K • Lambertian distribution • Dark bronze housing • Clear glass lens • 10% dimming for 0-10V applications • Universal voltage

Series Description
VWMH-L10/840-TL-DBZ-CGL-QS-DIM-UNV 1,000 lumens
VWMH-L17/840-TL-DBZ-CGL-QS-DIM-UNV 1,700 lumens

VWMV | Voltaire Mini Architectural Wall Pack

  • Provides security and accent lighting for walkways, entries, perimeters, and facades.
  • Intended for use in both uplight and downlight applications.
  • Blends seamlessly with a variety of architectural styles.
  • Purposefully modeled to allow runoff of dirt and water for an always-clean appearance.

Fixture Standards: 80 CRI • 4000K CCT • Lambertian distribution • Dark bronze housing • Clear glass lens • 10% dimming for 0-10V applications • Universal voltage

Series Description
VWMV-L10/840-TL-DBZ-CGL-QS-DIM-UNV 1,000 lumens
VWMV-L17/840-TL-DBZ-CGL-QS-DIM-UNV 1,700 lumens
A Visible Difference Since 1921
